| Technical parameters | Unit | HZS90 | |
|---|---|---|---|
| Theory prouducivity | m³/h | 90 | |
| Volume of mainframe | m³ | 1.5 | |
| Batcher | PLD2400QD-III | ||
| Batcher(volume perbin) | m³ | 15 | |
| Batcher(bin's amout) | 3 | ||
| Aggregate max scale | kg | 4000 | |
| Cement max scale | kg | 1000 | |
| Powder material max scale | kg | 300 | |
| Water max scale | kg | 400 | |
| Liquid additive max scale | kg | 40 | |
| The mixer's power | kw | 2×30 | |
| Lifting power | kw | 15 | |
| Whole power | kw | 110 | |
| Discharging height | m | 3.8 | |
| The whole weight | t | 37 | |
| Dimension (L×W×H) | m | 26.6×17.3×19.4 | |
| Feeding style | Belt | ||
| Calculating Precision | Aggregate | ±2% | |
| Powder material | ±1% | ||
| Water | ±1% | ||
| Additives | ±1% | ||
