Cloverdyn Plant
1 / 5
Modular assembly allows for local installation of each component. The entire mixing station frame can be completed quickly, saving significant time and labor, with finished products possible within five days.
No complex foundation is required. As long as the site flatness and hardness meet equipment standards, production can begin without intensive civil engineering investment.
The modular structure supports easy disassembly and overall relocation of the large frame, making it ideal for projects requiring site transfers.
Utilizes advanced computer network and automatic control technology. Features include proportioning, data storage, adjustment of parameters, and multi-language support for global operations.
Engineered for stability with low vibration. Features German steel wire rope, four-point limit anti-impact roof, and heavy-duty batching materials to ensure high safety factors and minimal maintenance.
Provision of regular equipment inspections, personnel training, and active technical service to ensure long-term stability and customer satisfaction.
Complies with environmental policies. All powder materials are handled in a sealed state, and the cement bin is equipped with dust collectors to minimize dust and noise pollution.
The overall structure is specifically designed for international transportation, allowing components to be loaded efficiently into standard containers for export.
| Item | Unit | Data |
|---|---|---|
| Product Model | - | MCB75 |
| Theoretical Productivity | m³/h | 75 |
| Mixer | - | JS1500 |
| Batching system | - | PLD2400 |
| Discharging Height | mm | 4100 |
| Aggregate Maximum Diameter | mm | 80 |
| Automatic cycle | s | 72 |
| Aggregate Weighting Precision | - | ±2% |
| Cement Weighting Precision | - | ±1% |
| Water Weighting Precision | - | ±1% |
| Additive Weighting Precision | - | ±1% |
| Total Power | KW | 133 |
